Stäubli Electrical Connectors Products
Railway Catalogue

Connection Solutions for Railway

As industry partner and key supplier in the international railway sector for more than 30 years, Stäubli has a clear insight into customer’s challenges and expectations, such as service continuity, extreme weather conditions and mechanical stresses. Stäubli provides an effective response with optimized solutions, whether for high-speed, mainline, suburban or regional trains, or tramways and underground railways.

Positioning and Fixing Option for MPC
Positioning and Fixing Option for MPC Flyer

Positioning and Fixing Option for MPC

Easy integration of pluggable connectors
Connections along the traction chain are often hard to implement because space and accessibility are very limited, or because the cables are too short. The higher tensile force on the connector is another issue.
Modular Power Connector MPC3-BS – angled
Modular Power Connector MPC3-BS – angled Flyer

Modular Power Connector MPC3-BS – angled

The compact solution is suitable for the following areas of application: inter-car connection on the roof or under car, traction or auxiliary converter outputs, battery outputs, and body to bogie and body to motor connection.
Connectors for battery packs CT-HE
Connectors for battery packs CT-HE Flyer

Battery Pack Connector

The connectors described in this document meet the specific requirements of the railway industry and are particularly suited for the use in railway rolling stock. These connectors are based on the components of our modular connector system CombiTac.
Modular Power Connector MPC
Modular Power Connector MPC Flyer

Modular Power Connector - For rolling stock system, 200A - 700A, up to 3600V, 10mm² to 240mm²

This product range is designed to carry out the electric connections between several functions of the electrical chain of traction present on railway rolling stock. MPC has the advantage of a universal multi-application, compact and modular solution, through the rationalization and the standardization of the common components.
