Our single-pole, insulated Ø 6mm panel receptacles and couplers fitted with the proven MC Multilam. These connectors are made of silver plated brass with plastic insulation.
Designed for continuous current loads up to 125A, they are primarily used as couplers and connecting elements in laboratories, testing facilities and whenever con-ventional Ø 4mm measuring equipment is inadequate.
The MC locking system AR operates on a "push-pull" principle. It is self-locking when connected. Disconnection is effected by an axial displacement of a coupling ring: first push, then pull to disconnect.
Electrical grounding hinge – EGH
The lower part of the hinge is mounted on the cabinet, and the upper part on the door. The EGH replaces the ground braid between the door and the
cabinet it facilitates easier removal of the door and guarantees reconnection of the ground on reassembly.
Round Connectors Ø 21mm / 1000V, 1000A
The single pole, insulated Ø 21mm round connector complements the well established
10BV and 16BV systems, adding to the program a particularly powerful solution with
current carrying capacity up to 1000A for mobile power supply.
Shielded connector 21BV-GS / 600A, 1000V
The plug connector 21BV-GS was developed as a customerspecific solution on the basis of the tried and tested round connector 21BV.
The continuous shielding gives dependable protection from electromagnetic influences.
SEM… Multipole Connector
The battery connector SEM for electric vehicles is suitable for internal battery to control unit or motor and external battery to charging station connections.
The connectors can be coded with hexagonal coding bolts, providing six coding positions for different operating voltages.
The self-extinguishing insulation housing is available as flat, two-pole mono-block construction or one-pole add-on housing.
It is resistant to mineral oils, petrol, commercial lubricants and cleansers commonly found in the motor vehicle industry.
The touch-protected plug and socket can be locked with a plastic fixing bracket.
