Roboticline
Roboticline Catalogue

Primary circuit connectors

For reliable power supply to medium-frequency welding units. Small in size but high in performance, equipped with MULTILAM Technology. With these connectors, the cable between transformer and welding gun can be subdivided into several sections, simplifying handling and maintenance. It is also possible to incorporate two pilot contacts for signal leads.

RobiFix Flyer
RobiFix Flyer

RobiFix - Primary circuit connector


Highly reliable, cost-effective and space-saving means of integrating power supplies in robotic dress packs and running them along robotic arms. This latest innovation does not require any special assembly tools.



RobiFix-MINI Flyer
RobiFix-MINI Flyer

Primary Circuit Connector RobiFix-MINI


The new, cost-effective Stäubli Electrical Connectors connector for primary circuit lines in welding applications. Thanks to its lightweight and compact design this series can be easily integrated into modern lightweight manufacturing concepts.



Crimping Flyer
Crimping Flyer

Crimping tool case CZK2


Stäubli Electrical Connectors recommends the use of this cordless hydraulic crimping tool together with the Stäubli crimping dies for crimping the Stäubli contacts. This tool guarantees a safe and high quality crimp termination.



E Roboticline Flyer
E Roboticline Flyer

Primary Circuit Connectors
(PCS250 range)


Our range PCS250 is serving as the extension to our PCS150 program and covers welding applications ranging from 180A up to 250A.
These high-performance power connectors are dedicated to demanding applications such as aluminum and multilayer sheet metal welding.



D Roboticline Flyer
D Roboticline Flyer

Flanged male sockets / Flanged female plugs


Matches Roboticline 2+PE



C Roboticline Flyer
C Roboticline Flyer

Panel mounting housing for welding transformers


Panel-mount housing for welding transformers, designed for a space-saving connection to the welding transformer. Compared to conventional housings such as our TAG series, they take up about 70mm less space.



B Roboticline Flyer
B Roboticline Flyer

New end housings EG-TS-M... with metric threaded cable glands


In April 1999 the European standard EN 50262 "Metric cable glands for electrical installations" was replaced by standards DIN VDE 0619, DIN 46319 and DIN 46320 "Glands for cables and leads with PG thread". Stäubli Electrical Connectors now offers both end housings with PG thread as well as with metric thread to fit our primary circuit connectors. For easier identification, the metric end housings are colored gray.



A Roboticline Flyer
A Roboticline Flyer

Primary circuit connectors for welding transformers


Multipole primary circuit connectors for electric welding transformers, consisting of an adapter plate for direct assembly to the welding transformer and a female plug for cable conductor cross sections of 25mm² or 35mm². Thanks to an opening in the adapter plate a bus distributor box may be attached.
