CombiTac - The Modular Connector System

Our modular connector system allows individual combination of power, signal, thermocouple, coaxial, fibre optic, pneumatic, hydraulic and bus connections in a compact frame or housing. Electrical contacts are equipped with our proven MULTILAM are available with crimp, screw or flow-solder terminals. For various kinds of applications including module technology, telecommunications, computer technology and machine control systems.

Coaxial 6 GHz Flyer
Coaxial 6 GHz Flyer

Coaxial unit 6 GHz

CombiTac solution for connecting 50 Ω RG coaxial cables through crimp or SMA termination for the transmission of data, digital audio and video signals up to 6 GHz.

Light Housing Flyer
Light Housing Flyer

Light housing for testing applications

The CombiTac IP20 plastic light housing with central locking is used in applications that require high density electrical signal connections.

PE Module Flyer
PE Module Flyer

Protective grounding of conductive housings

Appropriate ground protection is available for conductive DIN housings to protect users against electrical shock, according to IEC 61140.

          Go to the - CombiTac Configurator -
